Primary Crushing – APJ Series Jaw Crusher
Feeding Size:≤1000mm
Capacity:5-800T/H
【Applicable Material:】
Quartz, granite, basalt, limestone, river stone, sandstone, shale, iron ore, copper ore, gold ore etc.
【Applicable Fields:】
Widely used in various industries, such as mining, road and railway construction, building construction,water conservation and chemical industry etc.
Jaw crusher for sale Philippines is one of the common crushing equipment for the primary and secondary crushing processes. The jaw crusher machine is used for crushing various ores and bulk materials with a compressive strength of 147-245MPa. With the features of simple structure, high degree of intelligence, reliable operation, easy maintenance, and low maintenance costs, it has been widely used in these fields, like metallurgy, the chemical industry, building materials, transportation, and other industrial sectors.
Different Types of Jaw Crushers in The Philippines for Choices
Nowadays the primary jaw crusher for sale in the Philippines has been one of hot-sale mining equipment. In order to meet different customers’ requirements, Aimix Group has manufactured different types of APJ series jaw crushers for the Philippines customers, such as APJ-E type, APJ-V type jaw crusher, and APJ-X type, etc. You can check them below.
APJ-E Type
APJ-E series jaw crusher equipment is the classic model in crushing operations. In the market, it is called PE series jaw crusher machine for sale. It is suitable for crushing various hardness materials such as various rocks, ores, slag, concrete and construction waste. The jaw crusher capacity ranges from 1 tph to 800 tph. Besides, the APJ-E type jaw crusher feed size is about 130-1000 mm. To meet customers’ demands, Aimix has manufactured various models of crushers for choices, such as APJ-4060E, APJ-5075E, APJ-6090E, APJ-8010E, APJ-9012E, APJ-1215E….. You can check the hot-selling models in the Philippines.
APJ-4060E Jaw Crusher
- Max. feeding size(mm): 340
- Discharging open size(mm): 40-100
- Capacity(t/h): 16-60
- Motor power(kw): 30
- Total weight(t): 6.7
APJ-5075E Jaw Crusher
- Max. feeding size(mm): 425
- Discharging open size(mm): 50-100
- Capacity(t/h): 40-110
- Motor power(kw): 55
- Total weight(t): 11.7
APJ-7510E Jaw Crusher
- Max. feeding size(mm): 630
- Discharging open size(mm): 80-180
- Capacity(t/h): 110-320/li>
- Motor power(kw): 90-110
- Total weight(t): 28
| Model | Feed opening (mm) | Max feeding size(mm) | Output size(mm) | Capacity(t/h) | Power(kw) | Overal dimension(mm) | Weight(t) |
| APJ-1525E | 150×250 | 130 | 15-45 | 1-4 | 5.5 | 896×745×935 | 0.8 |
| APJ-2540E | 250×400 | 210 | 20-80 | 5-20 | 15 | 1450×1315×1296 | 2.8 |
| APJ-4060E | 400×600 | 340 | 40-100 | 16-60 | 30 | 1565×1732×1586 | 6.7 |
| APJ-5075E | 500×750 | 425 | 50-100 | 40-110 | 55 | 1890×1916×1870 | 11.7 |
| APJ-6090E | 600×900 | 500 | 65-180 | 80-180 | 55-75 | 2305×1840×2298 | 16 |
| APJ-7510E | 750×1060 | 630 | 80-180 | 110-320 | 90-110 | 2450×2472×2840 | 28 |
| APJ-8010E | 800×1060 | 680 | 100-200 | 140-340 | 90-110 | 2610×2556×2800 | 30 |
| APJ-8710E | 870×1060 | 720 | 170-270 | 180-360 | 90-110 | 2260×2556×2800 | 31.5 |
| APJ-9012E | 900×1200 | 750 | 95-225 | 220-450 | 110-132 | 3335×3182×3025 | 49 |
| APJ-1012E | 1000×1200 | 850 | 125-280 | 280-550 | 110-132 | 3435×3182×3025 | 52 |
| APJ-1215E | 1200×1500 | 1000 | 150-300 | 400-800 | 160-220 | 4200×3732×3843 | 101 |
APJ-E Type Features:
- 1. Large crushing force and wide application range. The APJ-E type jaw crusher mining can realize lamination crushing, which can help save energy and reduce consumption.
- 2. It has adopted high-strength steel to weld the structure, which has reduced the weight of the equipment and strengthened the strength.
- 3. The jaw plate and lining plate are made of high-quality wear-resistant steel, which is water-toughened and heat-treated. The wear-resistant parts are with high surface hardness. Thus, the life span is longer.
- 4. The movable jaw plate can be reversed and used, which can greatly improve working efficiency.
APJ-V Type Large Jaw Crusher
From its name, we can conclude that the APJ-V big jaw crusher has the V structure chamber to crush the materials. Actually, it is same as the European type jaw crusher for sale near me in the Philippines market. In Aimix, it is manufactured based on years of experience on jaw crusher design and production. Compared with traditional APJ-E Type jaw crusher, it has the obvious advantages of excellent strength structure reliable equipment, higher crushing ratio, larger capacity, and lower cost. Customers can choose it for mining construction without hesitation. The APJ-V type jaw crusher size and capacity is about 65 tph to 800 tph. In addition, the range of APJ-V jaw crusher feed and product size is 420mm to 1000mm. For APJ-V type, there are several models for selecting: APJ-80V, APJ-100V, APJ-110V, APJ-140V, and APJ-160V.
APJ-110V Jaw Crusher Machine
- Max. feeding size(mm): 720
- Discharging open size(mm): 70-200
- Capacity(t/h): 190-450
- Motor power(kw): 160
- Weight(t): 25
APJ-125V Jaw Stone Crusher
- Max. feeding size(mm): 800
- Discharging open size(mm): 100-250
- Capacity(t/h): 290-500
- Motor power(kw): 160
- Speed(rpm): 36.7
| Model | Feed opening (mm) | Max feeding size(mm) | Output size(mm) | Capacity(t/h) | Power(kw) | Overal dimension(mm) | Weight(t) |
| APJ-80V | 510×800 | 420 | 40-175 | 65-220 | 75 | 2500×1750×1950 | 7.5 |
| APJ-100V | 760×1000 | 640 | 70-200 | 150-350 | 90-110 | 3100×1980×2490 | 20 |
| APJ-106V | 700×1060 | 600 | 70-200 | 150-400 | 110 | 3450×1900×2490 | 13.5 |
| APJ-110V | 850×1100 | 720 | 70-200 | 190-450 | 160 | 3750×2280×2880 | 25 |
| APJ-125V | 950×1250 | 800 | 100-250 | 290-500 | 160 | 4870×2850×3570 | 36.7 |
| APJ-140V | 1070×1400 | 900 | 125-250 | 350-550 | 200 | 5100×3050×3790 | 45.3 |
| APJ-145V | 1100×1400 | 930 | 125-275 | 400-650 | 200 | 5300×3150×3890 | 53.8 |
| APJ-160V | 1200×1600 | 1000 | 150-275 | 500-800 | 250 | 5500×3250×3990 | 68.6 |
APJ-V Working Video
APJ-X Type Small Crusher
The APJ-X type is small jaw crusher for sale because it mainly crushes the materials to fine aggregates. Therefore, it is also named after fine jaw crusher. In Aimix Group, the mini jaw crusher for sale has small capacity ranging from 8 tph to 95 tph. The feeding size is from 120mm to 250 mm. In the Philippines, some of the customers choose to buy the jaw crusher small for self-using because of its lower prices. It is suitable for small-size personal projects. Here are some models for selection: APJ-2575X, APJ-2510X, and APJ-3013X.
| Model | Feed opening (mm) | Max feeding size(mm) | Output size(mm) | Capacity(t/h) | Power(kw) | Overal dimension(mm) | Weight(t) |
| APJ-1575X | 150×750 | 120 | 18-48 | 8-25 | 15 | 1380×1658×1025 | 3.5 |
| APJ-2575X | 250×750 | 210 | 25-60 | 13-35 | 30 | 1545×1667×1330 | 5 |
| APJ-2510X | 250×1000 | 210 | 25-60 | 16-52 | 30-37 | 1530×1992×1380 | 6.5 |
| APJ-2512X | 250×1200 | 210 | 25-60 | 20-61 | 37-45 | 1900×2192×1430 | 8.8 |
| APJ-3013X | 300×1300 | 250 | 20-90 | 25-95 | 55-75 | 1750×2320×1724 | 12.6 |
Hot-sale APY Series Mobile Jaw Crusher
Compared with above stationary jaw crusher, the jaw crusher can move among the construction sites. Besides, it can directly produce the finished aggregate without transportation. In terms of the choice of chassis, there are two kinds of choices in Aimix: tire type and crawler type. While, in general, we name the crawler type as track mounted jaw crusher and tracked jaw crusher for sale. The customer can choose any APY series mobile jaw crusher plant according to the actual working condition. Nowadays, the small portable jaw crusher for sale is widely applicable for the construction industry, sand and gravel plants, infrastructure projects, road construction projects, and other departments.
Working Principle of Jaw Crusher
- Generally, the hydraulic jaw crusher has two jaws: one jaw is fixed while the other one moves.
- The jaw crusher working principle is based on the reciprocating movement of the movable jaw that compresses and crushes the materials between itself and the fixed jaw, as the material enters the zone between the jaws.
- The movable jaw moves back and forth against the fixed jaw, and the material fed from the top of the machine is compressed between the two, breaking it into smaller pieces.
- As the movable jaw leaves the fixed jaw, the crushed material is discharged from the crusher at the bottom, and the size of the discharged material is determined by the gap between the jaws.
Here is a working video that has shown how the jaw crusher works. You can have a knowledge of it after visiting the jaw crusher youtube video below.
Jaw Crusher VS Cone Crusher
Jaw crusher and cone crusher are the two types of crushers commonly used in the Philippines market. What is the main difference between jaw and cone crusher? Here is a simple analysis of them. You can check for references when choosing a crusher machine for sale.
| Jaw Crusher | Cone Crusher | |
| Crushing Stage | used as a primary crusher and second-class crusher | used as the secondary crusher or three-stage crusher machine |
| Crushing Principle | adopting the extrusion process between the grinding wall and the crushing wall | adopting the extrusion process between the moving jaw plate and the static jaw plate |
| Adapt To Different Material | dealing with materials with high moisture content and high viscosity without blocking | not suitable for crushing viscous materials containing moisture. |
| Feeding Way | even material feeding, not full, materials in the jaw crusher chamber not exceed 2/3 of the crushing chamber height | full load material, directly feeding materials without vibration feeder. |
| Advantages | simple structure, low manufacturing cost, convenient maintenance, small machine height, easy to configuration | high productivity, less power consumption, work more stability, small vibration crushing ratio, product granularity is more uniform |
Based on the comparison, customers can choose a suitable one according to their requirements. In addition, the jaw crusher and cone crusher can cooperate. The matching of them is based on the crushing segmentation. Customers should consider whether the particle size of the jaw crusher can enter the cone crusher to form secondary crushing. If you wanna get a customized scheme according to your project, please contact us for solutions!
What Should You Consider When Selecting A Jaw Crusher in The Philippines?
Before investing in a jaw crusher China for business, it is necessary for customers to consider a lot of things, such as capacity, feeding size, discharge aggregate size, applications, prices, service, returns, etc. Here I have listed significant parts that should be noticed.
1. Feeding size
The first thing that should be considered is the feeding size. The customer should know the size of the aggregate of materials before crushing. Because the model of jaw crusher Philippines is divided based on the feeding sizes.
2. Capacity
The capacity is also should be taken into consideration. If you plan to crush large quantities of aggregate in a day, it is better to choose the large-capacity crusher. Otherwise, the small size is more suitable.
3. Price
The primary jaw crusher price is the most important aspect for customers to consider. It is important for customers to choose the right one with the best jaw crusher machine price, which is under budget. The price range of Aimix best jaw crusher for sale is 3000USD-130000USD. Different models have various prices. Contact us and get the latest price now!
4. Service
As for a large mining construction machine, it is necessary for customers to choose one from a reliable manufacturer that can provide considerate service. As we all know, the crushing line is a customized solution for customer. Therefore, it needs constant communication, following up, and feedback. Best service can help save a lot of maintenance after-sales service costs for customers.
Choose Aimix Jaw Crusher Machine Manufacturer in The Philippines
Maybe you can search many jaw crusher manufacturers in the Philippines market, but which of them is trustworthy? Search the jaw crusher supplier information online and you can get many results and view them one by one. Among them, it is easier for customers to find Aimix crushing machine manufacturers. As one of the reliable and reputable manufacturers in the Philippines, you can choose to cooperate with us without hesitation! Here are some reasons why choose us! Check the reasons below!
- 1. Over 40 year’s manufacturing experience since 1982. Aimix has accumulated mature experience and advanced technology to produce the best machines for customers.
- 2. Branch offices established in Manila, Philippines. Customers can visit and communicate with local sales face to face.
- 3. Warehouses available to provide spare parts promptly. If there is something wrong with the component of the diesel engine jaw crusher during working, it is easier to exchange. Because there are so many spare parts in stock. Customers can get parts soonest!
- 4. Local crushing lines for free visiting! Aimix has exported many crushing machines to the Philippines market. Now the rock crushing plants have covered over 15 cities, including Manila, Cebu, Davao, Bacolod, Calapan, Lapu-Lapu, Ormoc, etc. Before making an order, we can arrange for visiting the jaw crushing plants nearby on-site.
- 5. Turnkey service. We can provide customers with turnkey service for those who don’t have import experience. The customer just needs to pay for the crushing plant. Then Aimix would deal with all issues, including delivering, customs clearance service, installation, testing, and debugging service.
- 6. Local after-sales service. Aimix has a local after-sales service team in the Philippines to solve customers’ problems. If the stone crusher machine is out of order, customers can contact the service team. The service staff would come on-site for free jaw crusher maintenance.
Based on the above reasons, you can trust us and cooperate with us without hesitation! If you are interested in the jaw crushers, please contact us right now! Contact us through the following form, email, tel, or WhatsApp! Then our sales would reply to you in 6 hours!
