Stationary concrete pump for sale in the Philippines is one of the hot-selling concrete pumping equipment for various kinds of construction projects, such as expressway construction, tunnel construction, port project, municipal engineering project, building construction, and so on. It has the same appearance and function as a trailer concrete pump. Because without the chassis and tires on the trailer concrete pump, it is a stationary one. However, the customers also can move it easily on-site under a trailer or tractor dragging. Check the detailed introduction below please.
Model of Aimix Stationary Concrete Pump for Sale
- Aimix stationary pumpcrete Philippines is more suitable for those projects that don’t need to move the machine frequently and need to pump a lot of concrete in one day.
- Equipped with the additional pipelines, static concrete pump for sale can reach the distance that the ordinary concrete pump can’t reach. Therefore, Aimix stationary pumps are well-received among customers in the Philippines.
- As for its power, there is diesel concrete pump stationary and electric concrete pump stationary for sale.
- Aimix has produced three standard models of stationary pumps for reference: 40 m3/h, 60 m3/h, and 80 m3/h. Based on the diesel and electric power, models are as follows:
- Diesel Concrete Pump: ABT40C, ABT60C, and ABT80C
- Electric Concrete Pump: ABT40D, ABT60D, and ABT80D
Stationary Concrete Pump Specification
| Items | Units | Perameters | |||
| ABT40C | ABT60C | ABT80C | |||
| whole performance of machine | Max. theo. concrete output(L./H) | M3/h | 40/26 | 67/45 | 84/45 |
| Max.concrete pumping pressure(H./L.) | MPa | 10/8 | 13/7 | 16/7 | |
| Distribution valve type | S Valve | S Valve | S Valve | ||
| Concrete cylinder diameter×stroke | mm | Φ180×1200 | Φ200×1650 | Φ200×1800 | |
| Hopper capacity x feeding height | L/mm | 400/1100 | 800/1400 | 800/1400 | |
| Outlet diameter | mm | Φ150 | Φ180 | Φ180 | |
| Power system | Diesel engine model | Weichai | Wechai | Wechai | |
| Diesel engineering power | KW | 82 | 129 | 176 | |
| Rotate speed | r/min | 2200 | 2200 | 2200 | |
| Hydraulic system | Circuit type | Open circuit | Open circuit | Open circuit | |
| Pumping system pressure | MPa | 32 | 32 | 32 | |
| Mixing system pressure | MPa | 10 | 10 | 10 | |
| Capacity of oil tank | L | 370 | 560 | 560 | |
| Other parameters | Max. Theoretical Vertical/Horizontal Conveying Distance | m | 120/500 | 180/1000 | 260/1200 |
| Max. aggregate diameter | mm | Slick/scree:40 | Slick/scree:40 | Slick/scree:40 | |
| Inside diameter of delivering pipe | mm | Φ125 | Φ125 | Φ125 | |
| Dimensions：length×width×height | mm | 5000x1850x1700 | 5800x2000x1750 | 6300x2100x2350 | |
| Total weight | kg | 4500 | 6500 | 6900 | |
| Items | Units | Perameters | |||
| ABT40D | ABT60D | ABT80D | |||
| whole performance of machine | Max. theo. concrete output(L./H) | M3/h | 40/26 | 60/36 | 84/46 |
| Max.concrete pumping pressure(H./L.) | MPa | 10/8 | 13/7 | 16/9 | |
| Distribution valve type | S Valve | S Valve | S Valve | ||
| Concrete cylinder diameter×stroke | mm | Φ180×1300 | Φ200×1650 | Φ200×1800 | |
| Hopper capacity x feeding height | L/mm | 400/1250 | 800/1400 | 800/1400 | |
| Outlet diameter | mm | Φ150 | Φ180 | Φ180 | |
| Electrical engineering power | KW | 45 | 90 | 110 | |
| Rotate speed | r/min | 1480 | 1480 | 1480 | |
| Hydraulic system | Circuit type | Open circuit | Open circuit | Open circuit | |
| Pumping system pressure | MPa | 28 | 28 | 32 | |
| Mixing system pressure | MPa | 10 | 10 | 10 | |
| Capacity of oil tank | L | 370 | 560 | 560 | |
| Other parameters | Max. Theoretical Vertical/Horizontal Conveying Distance | m | 120/500 | 160/800 | 200/1000 |
| Max. aggregate diameter | mm | Slick/scree:40 | Slick/scree:40 | Slick/scree:40 | |
| Inside diameter of delivering pipe | mm | Φ125 | Φ125 | Φ125 | |
| Dimensions：length×width×height | mm | 4500x1750x1600 | 5500x2000x1750 | 5800x2100x2350 | |
| Total weight | kg | 3200 | 6000 | 6300 | |
Hot-Sale Model in The Philippines – ABT40C Diesel Static Line Concrete Pump
- Among all stationary pumps for sale in the Philippines, the model ABT40C is the most popular in the market.
- ABT40C is a diesel concrete pump. It is a small concrete pump with a capacity of about 40 m3/h. Thus, it is appropriate for small and medium construction items, such as foundations, roads, houses, buildings, tunnels, harbors, parking lots, etc.
- Because of the reliable performance of our concrete stationary pump, our products have won a good reputation in the Philippines. More and more customers in the Philippines are willing to buy one from Aimix company.
- Up to now, Aimix has exported many sets of stationary pumps to the Philippines. Now Aimix static line pumps are widely applied in these regions and cities: Manila, Cebu, NRC, Davao, Quezon, Caloocan, Zamboanga, Batangas, Baguio, Caloocan, Cavite, Lapu-Lapu,, etc. Check the following exporting cases and applications.
- Model: ABT40C
- Project: for warehouse construction
- Site location: In Manila, Philippines
- Model: ABT40C
- Project: for foundation construction in rural places
- Transporting Destination: to Davao, Philippines
- Model: ABT40C
- Project: for building construction in urban areas
- Delivering Destination: to Cebu, Philippines
- Model: ABT40C
- Project: for road construction in urban areas
- Delivering Destination: to Cavite, Philippines
Other Models of Stationary Pumps At The Construction Sites in The Philippines
Apart from the hot-sale ABT40C model, other models of Aimix station concrete pumps for sale also have been exported to the Philippines, especially the AB30C and ABT60C. They are widely applied to different kinds of projects. Check some cases of them below.
Wide Applications of Aimix Stationary Pumps All Over The World
Working Site of ABT40C Static Line Concrete Pump In Myanmar for 3-Story Building Construction
ABT40C Diesel Stationary Concrete Pump Working in Indonesia for 4-Story Hotel Building Construction
ABT40C Machine Pumping Concrete In Uzbekistan for Factory Warehouse Construction
Stationary Pump With Concrete Truck for Construction
The stationary pump for concrete can cooperate with concrete mixer truck for construction projects. After the concrete mixture is blended in the truck, then loaded into the station pump concrete, last transported through pipelines. In this way, they can greatly improve working efficiency and shorten the construction period.
1. With Concrete Mixer Truck
- In general, the concrete mixer truck would load the concrete mixture from the concrete batching plant.
- It would mix the concrete mixture with drum rotating during the process of transportation.
- After arriving at the construction site, it would discharge the mixture into the hopper of the concrete station pump.
- Last, the stationary pump would deliver the mixture through the pipelines.
Here is the working video of the Aimix ABT60C diesel concrete pump with a concrete truck on-site in the Philippines. Customers can choose the combination for their construction, especially building construction on site.
2. With Self Loading Concrete Mixer Truck
- Firstly, the self loading mixer could load the aggregate through the bucket itself. Load the mixture into the mixing drum.
- Secondly, the mixing drum would blend the aggregate evenly. Discharge the mixture into the concrete pump hopper after mixing.
- Last, the concrete pumps begin to work and pump the concrete mixture to higher and further distances through pumping pipes.
Self Loading concrete mixer with pump is a popular combination among customers in the Philippines. A lot of customers in the Philippines have purchased the self-loading mixer with pump for their construction projects, especially for foundation, house and building construction. You can check its working video below.
Characteristics of Aimix Stationary Concrete Pumps
- 1. It can pump the concrete mixture to where it is needed. The pumping distances range from 120m to 200m vertically; 500m to 1000m horizontally.
- 2. Aimix concrete stationary pump has adopted an S valve to reduce the failure rate, especially for pipe blocked.
- 3. All of the core components are imported from foreign famous brands to prolong their service life.
- 4. The advanced electric control system is easier to operate and maintain. It helps save a lot of labor, time, and cost.
- 5. Remote controlling device. Using the device, customers can operate it remotely to improve safety.
How To Choose A Credible Stationary Concrete Pump Manufacturers?
Before purchasing a hydraulic stationary pump, you need to look for a credible stationary pump. An excellent concrete machinery manufacturer can not only provide you with a good machine but also affordable stationary concrete pump price. Here are some tips you should consider before making a decision.
Considering The Strength of Company
You can learn a company’s strengths from several different aspects. The quality of stationary concrete pumps is important. You can know how they produce the static concrete pump and how their staff works by visiting their factory and office. As a trustworthy concrete machinery supplier, our Aimix Group is delighted that you can visit our company. What’s more, since Aimix was founded, we have gotten many certificates and have applied for many patents for our technological innovation.
Checking Customers Feedback
You can learn the quality of machines and the company’s strengths through the feedback of their clients. Up to now, our concrete pump stationary has been transported to many countries and cities, including the Philippines. Our concrete machines have worked in Manila, Cebu, Zamboanga, Laguna, Davao, Subic, and so on. We have our own office in the Philippines. You can get real feedback about us from these clients.
Knowing Considerate Service
Suppliers can provide you with pre-sale and on-sale services. But few of them can offer a complete service, including pre-sale, on-sale, and after-sale service. If you choose Aimix concrete pump, the service content has professional advice, accompanying to visit our company, guidance of installation and debugging, training, teaching maintenance and repairing methods, regular visiting, etc. We believe that you will satisfy our sincere and thoughtful service. In addition, Aimix has branch offices and LBS centers in the Philippines for providing professional after-sales service for local customers.
Therefore, if you have other questions or are interested in our concrete pump machine price, welcome to contact us through the following inquiry form or email or WhatsApp! Then our sales will reply to you as soon as possible! Email: market11@aimixgroup.com.
